Measure cabinet hardware before buying replacements. Use practical charts, calculators and checklists for drawer slides, shelf pins, cabinet hinges and drawer pulls.
Start here: if a part has to fit a hole, cabinet opening, slide length or screw spacing, measure first. The wrong-size part is the real enemy.
Drawer Slide Size Calculator
Measure drawer box depth, cabinet depth and side clearance before buying replacement drawer slides.
Shelf Pin Size Chart
Compare 5mm, 1/4 inch, 6mm and 7mm shelf pins before ordering replacement pegs.
Drawer Pull Hole Spacing
Measure center-to-center screw spacing and convert common pull sizes between inches and millimeters.
Cabinet Hinge Overlay Chart
Calculate door overlay and understand full overlay, partial overlay, half overlay and inset hinge terms.
Fix A Drawer That Will Not Close
If a soft close drawer leaves a gap, bounces back or feels stiff, start with alignment and seating before buying new slides.
What Cabinet Part Are You Measuring?
| Part | Measurement that matters | Common mistake | Start page |
|---|---|---|---|
| Drawer slides | Drawer box depth, cabinet depth, side clearance | Measuring the drawer front instead of the box | Drawer slide guide |
| Shelf pins | Hole diameter or pin diameter | Assuming 5mm and 1/4 inch are the same | Shelf pin chart |
| Drawer pulls | Center-to-center screw-hole spacing | Buying by total handle length | Pull spacing guide |
| Cabinet hinges | Overlay, cabinet type, cup diameter, mounting plate | Confusing half overlay with 1/2 inch overlay | Hinge overlay chart |
How Cabinet Fit Lab Chooses Recommendations
Cabinet Fit Lab starts with measurement and fit, not brand hype. Product categories are mentioned only after the measurement problem is solved. If a page has not tested a specific product hands-on, it should not pretend otherwise.
Use the guides to identify the correct size, type and compatibility requirements. Then confirm the final product listing or manufacturer sheet before buying.
Core Rule
Measure the part that actually controls fit. For drawer slides, that is not the decorative drawer front. For drawer pulls, it is not the overall handle length. For shelf pins, it is not the shelf thickness. For hinges, it is not just the word “overlay” in a product title.
